SWIPE TO EXPLORE EVERY DETAIL
AUDIO / Speakers
YOUR NEXT UPGRADE STARTS HERE.
Explore the product images and available details below. Contact the AUDIO team to confirm specifications and compatibility for your build.
Shipping and taxes confirmed before payment. No charge when you submit an order request.
ENGINEER YOUR SOUND
Audio Specifications
Parameter: Value
Model: NEO-WAVE-6.5
Magnet Material: Neodymium
Magnet Size (mm): 65*5
Voice Coil Size (inch): 1
Power RMS (Watt): 90
Power MAX (Watt): 180
SPL (dB): 96
Impedance (Ohm): 4
Frequency Response (Hz): 110 - 14,000
Voice Coil Wire: CCAW
This specified sensitivity is not directly connected with the sound pressure in the vehicle, and therefore should not be used as the sole indicator for comparison with other speakers.
Need more details? Ask | Model | NEO-WAVE-6.5 |
|---|---|
| Magnet Material | Neodymium |
| Magnet Size (mm) | 65*5 |
| Voice Coil Size (inch) | 1 |
| Power RMS (Watt) | 90 |
| Power MAX (Watt) | 180 |
| SPL (dB) | 96 |
| Impedance (Ohm) | 4 |
| Frequency Response (Hz) | 110 - 14,000 |
| Voice Coil Wire | CCAW |
No additional technical diagrams are published for this model. Explore the product gallery above.
